How to connect ptfe compensator to equipment

Application of pressure balance ptfe compensator joint in inlet and outlet pipeline of gas turbine in refinery.As shown in the figure, the bending pipe force balance ptfe compensator can not only compensate the displacement in the pipeline, but also make the smoke turbine free from the blind plate force generated by internal pressure.

Bend pipe force balance ptfe compensator is used to connect equipment to equipment, the function is to compensate the thermal expansion of pipeline between the two equipment, reduce the installation error of the force on equipment, convenient installation.The use of bending pipe force balance ptfe compensator can make the equipment free from blind plate force caused by internal pressure, improve the mechanical condition of the equipment, and make the equipment easy to be stable.

Ptfe compensator is used in the inlet and outlet of pump as a soft coupling.A universal ptfe compensator is installed on the inlet and outlet pipelines of the pump to compensate the thermal expansion of the pipeline, reduce the thrust of the pipeline thermal expansion on the pump, or absorb the vibration generated by the pump during operation.

Ptfe compensator can be used for flexible connection between storage tank and pipeline.In recent years, oil field, the bigger the depot, chemical storage tank is built, as a result of the limitation of geological conditions, the basic natural sink tank and import and export pipeline position change, causes the damage of connecting line and tank wall, so in the import and export of pipeline of storage tank installation teflon compensator to compensate displacement or metal hose.

Ptfe compensator is also widely used in iron and steel industry.Large diameter ptfe compensator and rectangular ptfe compensator are mainly used in large blast furnace and hot air furnace.For example, different types of ptfe compensators are used in the pressure relief piping system and blast furnace body system of blast furnace top equipment.A universal ptfe compensator is installed in the air supply branch pipe of the furnace body, which can not only compensate the displacement of the pipe, but also reduce the installation stress.
